Sliding gate AcousticLine 45 dB

Description

Jansen is also your professional partner for noise insulation. This is neccessary where loud noises can enter from outside into a building, noises from inside to outside or noises within the building.

  • 45 dB
  • Approved to DIN EN ISO 140-3

Product description

Gate leaf

The door leaf consists of several 300 - 1100 mm wide elements (depending on the door width). The separate elements are joined to a sturdy door leaf through a special linking system. The thickness of the door leaf is only 63 mm. The surface consists of zinc-coated 1,5 mm thick steel sheets. The running-in profile and the labyrinth profile are zinc-coated. Soundproofing sliding door certified according to DIN EN ISO 140-3. This door reaches a soundproofing value of 45 dB (Rw,P). Higher soundproofing requirements and special equipment are available on request.

Guide rail

Each door element is guided in ball bearing mounted castors. The cold-milled, zinc-coated C-profiles are mounted to the ceiling by means of brackets. The guide rail casings are zinc-coated.

Floor guidance

The floor guidance is located laterally of the clear width.

Equipment

As fittings a C-shaped handle is used on the opposing wall, a shellshaped handle on the wallside. The opening of the door is limited by end position dampeners which are mounted on consoles. The door closes automatically due to closing weights, while a constant closing speed is ensured by a hydraulic closing speed control. As a standard feature a free-run device enables the door to be handled easily under normal application conditions. An electric drive with dead-man's control or pulse contact control is possible.

Media & downloads
Technical details

Bedienelemente

  • Schlüsseltaster
  • Zugschalter
  • IR-/ Radar- Bewegungsmelder
  • Funk
  • Induktionsschleife
  • Unter-Glas-Auslösetaster

Beschichtung

  • RAL
  • NCS
  • DB

ElektrischeOptionen

  • Zeitschließung
  • Impulssteuerung

RWP

  • 25 - 35 dB
  • 39 - 45 dB

clear width [mm]

  • 7,000 mm

clear height [mm]

  • 4,500 mm

SeitenplatzAntriebsseite

  • 496 mm

SeitenplatzLagerseite

  • 147 mm

Sicherheitsausstattung

  • Blitzleuchte
  • Light barrier

Sturzhoehe

  • 296 mm
